Technical specifications
| Model | FGM 800 | FGM 1100 | FGM 1450 |
| Paper Material | Cardboard200-800 gsm,corrugated board reach E-flute&B-flute. | Cardboard200-800 gsm,corrugated board reach E-flute&B-flute. | Cardboard200-800 gsm,corrugated board reach E-flute&B-flute. |
| (W*L)Max Paper Size | 800*900mm | 1100*1000mm | 1450*1000mm |
| Min Paper Size | 135*60mm | 270*60mm | 270*60mm |
| Max Belt Speed | 375m/minute | 375m/minute | 300m/mm |
| Power Source | 3-phase 380v 50Hz | 3-phase 380v 50Hz | 3-phase 380v 50Hz |
| 4-corner or 6-corner box,4-times fold bottom lock box | 10Ton | 10.5Ton | 11Ton |
| Twice Fold & bottom Lock box | 8.5Ton | 9Ton | 9.5Ton |
| Twice Fold one side glue box | 7.5Ton | 8Ton | 8.5Ton |
